ALUMINIUM BODY ROTARY GEARED LIMIT SWITCHES

MODEL - AL/GRLS

Rotary Limit Switch GRLS is designed to interrupt the power supply to a motor when the moving load reaches the designated extreme positions of its travel range.

Functionality:
This device operates through two or more contact elements, which are activated by corresponding rotating cams. These cams are mounted on a cam shaft that rotates at a fixed speed ratio to the motor shaft. The cams can be adjusted continuously, allowing precise positioning to cut off the motor supply and halt the motion at the desired travel point.

Uses:
Rotary Geared Limit Switches are ideal for applications with reversing drives, such as hoists, winches, rolling mills, and various other mechanisms in steel plants, including coke ovens and feeding machinery, among others.
